V SHAPED BAFFLE LOUVERS

Ultrasil make V-Shape baffle Cladding takes full consideration of various decorative factors in the public places, building, considering the practical needs and visual needs, this product can hide all the plumbing pipes the product is easy to be installed. It is available in range of sizes and with a choice of finishes to enhance the architectural appearance of a building.

Passages, Balconies, Lift Lobbies, Cover ducts of Residential & Commercial Projects.

  • Panels : V 50mm / 75mm wide, 50mm / 75mm / 100mm deep, length up to 3 mtr.
  • Material : Panel make 0.45 / 0.50mm Galvanized Steel & 0.55mm Alu Zinc, 0.65mm Aluminium -TCT.
  • Carrier : 20mm wide, 40mm deep of 0.60mm thick Black Coil Coated Galvanized Steel to hold panel in GAP module of 25mm / 50mm or Customized.
  • Perforation :
  • Paint Finish : Finish surface with Corrosion Resistive Exterior HYPERCOTE Powder Coating warranty of 10 Year for Exterior applications, preferred with visible & back (both) side powder coated.
  • Suspension :
